40" Standard Equalizing Table Slide (79" Opening)
Volume Discounts
Save 5% when ordering 24 or more pieces of the same product
Save 10% when ordering 50 or more pieces of the same product
Save 20% when ordering 100 or more pieces of the same product
*Discounted pricing reflected in cart
*All wood components are unfinished. Learn more about wood types or request a quote.
PRODUCT INSTRUCTIONS
(Click to view PDF)
All Table Slides are Sold as a Pair (one left, one right)
While our slides are built to be structurally sound, we do recommend using center support legs for extremely long or heavy tables.
The 40" standard equalizing slide is the perfect hybrid for your next table design! By combining the rack and pinion mechanism for the standard design, you are now able to create a long 5-legged table design. This slide is specifically designed to allow for a standard 4-legged table to be extended with a center support leg. The camber is specifically adjusted to support the center of your table for added support.
This table slide has an opening of 79", allowing ample space for leaves to be added to your table design. When fully extended, this table slide is 118 3/4". Make memories with the entire family gathering around a 5-legged table design that's you've created!
It is important to select the correct table slide:
- Standard table slides: A standard slide is designed for use on a 4 leg table, where the distance between the legs on each end of the table increases as the table is opened. A standard slide develops a camber to compensate for sagging in the center of the table.
- Equalizer table slides: Tabletops that are supported on a single pedestal require an equalizer slide that incorporates a rack and pinion system to ensure that the tops open and close easily while staying in balance. An equalizer slide is designed for use on a pedestal table, as it develops a camber to compensate for sagging at the ends of the table.
For more information about our Table Slides including helpful tips on installation check out our table slides information page.
Related Blog Posts
- How to Choose & Install Table Slides February 18, 2025
- Tips for Caring for Wooden Table Slides December 5, 2024
CAD Drawings
Related Products
-
2025-01-30 Material: Soft Maple (paintgrade)
Slides were fine. Well made and well designed.
-
2024-11-08 Material: Soft Maple (paintgrade)
Works nice and smooth
-
2023-11-16 Material: Soft Maple (paintgrade)
Haven’t installed it yet.
-
2023-06-08 Material: Soft Maple (paintgrade)
Good quality product
-
2023-06-02 Material: Soft Maple (paintgrade)
replacing existing slides for more opening space.
My fellow woodworkers to even competent DIYers
Great quality -
2023-03-11 Material: Soft Maple (paintgrade)
*****
-
2023-02-16 Material: Soft Maple (paintgrade)
Worked perfectly
-
2023-02-03 Material: Soft Maple (paintgrade)
Used the slide on a table I built out of cherry and would suggest it to anyone needing a slide., if I was doing it over I would go with a thicker top, mine was just over 3/4" .
-
2021-09-27 Material: Soft Maple (paintgrade)
These were wasy to install and understand, they are sturdy and precise. Definitely will buy again
-
2021-06-26 Material: Soft Maple (paintgrade)
Excellent dining table extension device already installed and will very likely be purchased again.
-
2021-02-19 Material: Soft Maple (paintgrade)
I didn't expect finger joint item, but product is fully serviceable.
