30" Table Slide (75" opening)
Volume Discounts
Save 5% when ordering 24 or more pieces of the same product
Save 10% when ordering 50 or more pieces of the same product
Save 20% when ordering 100 or more pieces of the same product
*Discounted pricing reflected in cart
*All wood components are unfinished. Learn more about wood types or request a quote.
All wooden table slides are sold as a pair (one left, one right). You need both in order for the extension to work, but they do not have to be installed to a particular side of the table.
Our 30" standard table slide is ideal for four-legged tables. It creates camber in the center that prevents the table from sagging. Each slide has eight holes pre-drilled into it for easy attachment to a table top. Please note that table top mounting screws are not included.
- Length of the slide when closed: 30"
- Length of the slide when fully extended: 105"
- Width of slide when closed: 6" (constructed with 6 sections)
- Accepts six (6) 12" leaves
It is important to select the correct table slide and understand our three options. This is a standard table slide for four-legged tables. We also offer:
- Equalizer table slides (fixed frame): For tables supported by a single pedestal base. This slide incorporates a rack and pinion mechanism to ensure that the tops open and close easily while remaining in balance. This slide design develops a camber to compensate for sagging at the ends of the table.
- Standard equalizing table slide: A hybrid design of the standard slide and equalizing slide designed for five-legged tables. It combines the camber developed by the standard slide to prevent sagging in the middle of the table, with the rack and pinion system of the equalizer slide. It allows a large five-legged table to remain stationary and have smooth extension.
For more information about our table slides including helpful tips on installation check out our table slide information page. If you have any further questions, out customer service team is ready to help!
CAD Drawings
Related Products
-
2023-12-23 Material: Soft Maple (paintgrade)
Great product. Easy to install
-
2023-12-08 Material: Soft Maple (paintgrade)
Good
-
2023-05-23 Material: Soft Maple (paintgrade)
Rating is tentative given that I haven't yet installed the product in the dining table that I am refurbishing. Initial fit up of the product shows that it should work well. It appears to be well made and I'm excited about getting the table back from the refinishers so I can complete the installation. Watching one of the website videos made me confident that this product will work in my application.
-
2023-04-20 Material: Soft Maple (paintgrade)
Replace existing extension slide. Worked great and customer was thrilled.
-
2023-03-16 Material: Soft Maple (paintgrade)
Quality great.
Shipping miscalculated probably. -
2023-01-19 Material: Soft Maple (paintgrade)
USED ON LARGE DINING TABLE. VERY WELL MADE AND FUNCTIONS WELL.
-
2022-11-03 Material: Soft Maple (paintgrade)
I would highly recommend this company but not the distributers who carry your products. I wad given wrong info from them . So glad I checked what they told me with you. I avoided a painful mistake by listening to you.. Now I have a working table. Thanks.
-
2022-02-23 Material: Soft Maple (paintgrade)
I extended our dining room table just in time for company coming in March.
-
2021-05-13 Material: Soft Maple (paintgrade)
I ordered the product to replace the slides on an antique table. They installed easily and work great.
I would recommend the product to anyone doing a furniture restoration or building a table.
Quality is great. -
2021-04-12 Material: Soft Maple (paintgrade)
I have used these sliders on multiple tables over the last five years. Always very smooths and easy to use. Awsome quality and very affordable.
-
2021-04-01 Material: Soft Maple (paintgrade)
My sister-in-law has a farm house table that belonged to her grandmother, the original slide had broken parts and was worn out. I used the slide from Osborne to replace that worn out original. The quality of the new slide it super, it's slides very easily both when sliding the table out and back. My sister-in-law hasn't gotten her table back yet, but she is going to be very happy with the new slides.
-
2021-01-21 Material: Soft Maple (paintgrade)
The (wooden) dining table slide extender mechanism broke and, after an exhaustive internet search, found Osborne. Their website was very helpful in matching up the correct replacement part and ordering was seamless. The product was delivered quickly and in excellent shape. The installation directions were well written and easy to understand, not some broken English translation. If Osborne has the product you need, I highly recommend their products.
-
2020-05-04 Material: Soft Maple (paintgrade)
Replacement of table slide to accommodate an additional leaf.
-
2019-12-27 Material: Soft Maple (paintgrade)
excellent product,the table top slides are strong,well made and perfect.
-
2019-12-18 Material: Soft Maple (paintgrade)
Fantastic product!
