50" Equalizer Table Slide (49" opening)
Volume Discounts
Save 5% when ordering 24 or more pieces of the same product
Save 10% when ordering 50 or more pieces of the same product
Save 20% when ordering 100 or more pieces of the same product
*Discounted pricing reflected in cart
*All wood components are unfinished. Learn more about wood types or request a quote.
All table slides are sold as a pair (one left, one right). Although it does not matter which slide you install to which side of the table, you must have one of each for a complete set.
This equalizer table slide has been constructed with a camber to prevent table sagging over time. There are pre-drilled holes (eight per slide) to help with table top installation. Please note that table top mounting screws are not included. This table slide has a rack and pinion built-in allowing for smooth and equal extension.
- Length of the slide when closed: 50"
- Length of the slide when fully extended: 99"
- Width of slide when closed: 3" (constructed with 3 sections)
- Accepts four (4) 12" leaves
It is important to select the correct table slide:
- Equalizer table slides: Tabletops that are supported on a single pedestal require an equalizer slide that incorporates a rack and pinion system to ensure that the tops open and close easily while staying in balance. An equalizer slide is designed for use on a pedestal table, as it develops a camber to compensate for sagging at the ends of the table.
- Standard table slides: A standard slide is designed for use on a four-legged table, where the distance between the legs on each end of the table increases as the table is opened. A standard slide develops a camber to compensate for sagging in the center of the table.
For more information about our Table Slides including helpful tips on installation check out our table slides information page.
